Description
6 working modes
Depending on the load, operators can conveniently choose between 6 working modes designed to match engine speed, pump delivery and system pressure. Priority can be given either to speed, for more productivity, or to fuel consumption for lighter applications.
Electronic control system
Fuel consumption on the second hand Komatsu PC55 is lower by up to 5%.
The engine and hydraulic system are optimally controlled according to the operating conditions.
The hydraulic loss reductions also help reduce both fuel consumption and environmental impact.
Easier repairs
ORFS hydraulic face seal connectors and DT electrical connectors enhance the machine’s reliability and make repairs faster and easier. High durability bushings and a 500-hour engine oil change interval further lower operating costs.
Specifications for the Komatsu PC55 excavator:
| Category | Specification |
|---|---|
| Model | Komatsu PC55 |
| Operating Weight | 5,260 kg (11,593 lbs) |
| Engine Model | Komatsu 4D88E-6 |
| Engine Power | 29.1 kW (39 HP) @ 2,200 rpm |
| Fuel Tank Capacity | 85 liters (22.5 gallons) |
| Maximum Digging Depth | 3,835 mm (151 inches) |
| Maximum Reach at Ground Level | 5,965 mm (235 inches) |
| Maximum Dumping Height | 4,010 mm (158 inches) |
| Bucket Capacity | 0.16 m³ (0.21 yd³) |
| Overall Length | 5,500 mm (216.5 inches) |
| Overall Width | 1,960 mm (77.2 inches) |
| Overall Height | 2,550 mm (100.4 inches) |
| Tail Swing Radius | 1,680 mm (66.1 inches) |
| Ground Clearance | 345 mm (13.6 inches) |
| Hydraulic Pump Flow Capacity | 132 liters/min (34.9 gallons/min) |
| Hydraulic System Pressure | 24.5 MPa (3,553 psi) |
| Track Shoe Width | 400 mm (15.7 inches) |
| Ground Pressure | 32 kPa (4.6 psi) |
| Cabin | Enclosed with air conditioning (optional) |
| Control System | Pilot proportional hydraulic control |
| Attachments | Various buckets and hydraulic attachments can be used |
Please contact us for the details of the available Used Komatsu PC55 Mini Excavator .
